500A Socket HVIL Series Metal Socket 1Pin 14mm M10 Screw Holes ip67 A Key Straight Shield
Part No.:E1-1-H140-1AYN-T09
Tags:HVIL Socket,Metal,1Pin,Straight,6mm,A Key,Natural,M10 Screw Holes,500A
Features:
- 12 Months” Quality Insurance;
- Sealing, IP67,Touch-proof;
- Multiple coding positions;
Application:
- PDU,Battery,Motor,Motor Controller;
Specification
Technical Characteristics
Rated current | 16A,35A,50A,125A,150A,200A,250A,400A,500A |
Rated voltage | 960V AC/1000V DC |
Withstand voltage | 3000V AC |
Insulation resistance | ≥500MΩ |
Connection Type | Terminal machine |
Mating cycles | 100 times Min |
Number of positions | 1 pos/2 pos/3 pos |
Salt Spray | MAX 96h |
Operating Temperature | -40°C ~ +125°C |
IP Rating | IP67 IP6K9K(Mated) |
Shielding | 360° |
Material & Finish
Description | Material | Finish |
Shell | PA66,Zinc alloy | … |
Contacts | Cooper alloy,Silver plating | … |
Sealing body | Rubber | … |
Delivery & Payment
Drawing
