DIN 1.6/5.6 Connector Right Angled Plug Clamp Type for ST212

Part No.:RHT-618-0002

Tags：Cable Connector, plug/male, Angled/90°, ST212,DIN1.6/5.6, Clamp Type

Features:
  • 12 Months’ Quality Insurance;
  • FREE sample available for quality test;
  • Miniature design only requried limited space for installation;
  • Threaded coupling version ensure safty and high durability;
  • Good performance at 75Ω impendance and up to 1GHz frequency.
Ask a quote

Technical Characteristics

Frequency Range 0~1 GHz
Impendance 75 ohm
VSWR Straight type ≦ 1.3max / R/A type ≦ 1.5max
Dielectric Withstanding Voltage 1000 V rms
Working Voltage  335 V rms
Center Contact Resistance ≦ 4.0 mΩ  (Milliohms max.)
Outer Contact Resistance 2.0 mΩ  (Milliohms max.)
Insultation Resistance ≧ 10⁴ mΩ
Coupling M9 x 0.5 Thread
Contact Retention 6 lbs min.
Mating Durability ≧500 cycles (For Beryllium Copper Contact)
Environmental Characteristics -40°C ~ +155°C
