RHT-633-0011
RHT-633-0011

FME Connector Straight Cable Mount 2GHz Jack Crimp Termination 50Ω

Part No.: RHT-618-0201

Tags：Cable Connector, plug/male, Straight/180°, RG174,DIN1.0/2.3, Crimp Type

Features:
  • 12 Months’ Quality Insurance;
  • FREE sample available for quality test;
  • Compact design is ideal for limit space application and save space in delivery;
  • Push/pull mating is excellent for quick installation without vibrate loose;
  • Great performance with frequency up to 10GHz support high data rates.
  • High Quality with 30 days 100% Money back;
  • From the OEM Original Factory, same quality with much better price.
Ask a quote

Technical Characteristics

Frequency Range 0~4 GHz for 50 ohm, 0~2 GHz for 75 ohm
Impendance 50 ohm or 75 ohm
VSWR  Straight type ≦ 1.3max / R/A type ≦ 1.5max
Dielectric Withstanding Voltage 750 V rms
Working Voltage 250 V rms
Center Contact Resistance ≦ 6.0 mΩ  (Milliohms max.)
Outer Contact Resistance 3.0 mΩ  (Milliohms max.)
Insulation Resistance  ≧ 10⁴ mΩ
Coupling Push-pull
Contact Retention 4 lbs min.
Mating Durability ≧500 cycles (For Beryllium Copper Contact)
Environmental Characteristics -40°C ~ +155°C

Material & Finish

Description Material Finish
Body Cooper  Nickel
