HVIL Series 2 Pin Metal Plug 16A/23A/35A A Key High Current Plastic Electric Car Connectors

Part No.:E1-1-S036-2AYN

Tags:HVIL Plug,Metal,2Pin,Straight,3.6mm,A Key,Natural,Crimp 2.5mm²/4mm²/6mm²,16A/23A/35A

Features:

  • 12 Months” Quality Insurance;
  • Sealing, IP67,Touch-proof；
  • Multiple coding positions;

Application:

  • PDU,Battery,Motor,Motor Controller;
Ask a quote

Technical Characteristics

Rated current 16A,35A,50A,125A,150A,200A,250A,400A,500A
Rated voltage 960V AC/1000V DC
Withstand voltage 3000V AC
Insulation resistance ≥500MΩ
Connection Type Terminal machine
Mating cycles 100 times Min
Number of positions 1 pos/2 pos/3 pos
Salt Spray MAX 96h
Operating Temperature -40°C ~ +125°C
IP Rating  IP67 IP6K9K(Mated)
Shielding 360°



Material & Finish

Description Material Finish
Shell PA66,Zinc alloy …
Contacts Cooper alloy,Silver plating …
Sealing body Rubber …
