Micro Female USB 5 Pin SMT Type B 180 Degree for PCB Mount

Part No.:RHT-692-1255

Tags:Micro USB,Type B,5Pin,Straight/180°,Female/Jack,SMT,PCB Mount,5.65-4.85


  • Micro USB,Type B,5Pin,Straight/180°,Female/Jack,SMT,Through Hole,PCB Mount;
  • More compact than Mini USB, meets environmental, health and safety requirements;
  • Full metal shielding, Flexible application;
  • Easy and Quick usage, Convenient recharging and communication;
  • High Quality with 30 days 100% Money back;
  • From the OEM Original Factory, same quality with much better price.

Technical Characteristics

Volatage Rating 100V AC (rms)
Current Rating 1.0A MAX
Contact Resistange 10 milliohms max
Insulation Resistangee 1000M ΩMin
Dielectric Withstanding Voltage 500 V DC/1min
Durability 10,000 cycles
10,000 cycles 35N max
UNmating force 10N
Operating Temperature -55°C to +85°C

VSWR: Voltagge Standing Wave Ratio

Material & Finish

Part Material Finish
Housing High Temperature Polymer UL94V-0
Shell Stainless Steel Nickel Plating
Contact Copper Alloy Au over nickel
