Solder SCSI Connector 14 Pin Straight Male with Plastic Shell Solder Type

Part No.:RHT-690-1007

Tags: SCSI,14Pin,Single Ports,Male/Plug,Straight/180°,for Cable,Solder Type,Gold

Features:

  • 12 Months” Quality Insurance;
  • FREE sample available for quality test;
  • Excellent I/O connector;
  • Highly reliable for high density packaging;
Ask a quote

Technical Characteristics

 Current rating 1.0A
 Insulator resistance >500MΩ (minimum)
 Contact resistance 35mΩ (maximum)
 Dielectric withstanding 500V AC/minute
 Insulation Resistance  1000M MIN.
 Mechanical operations up to 500
 Operating Temperature -55°C TO +105°C

Material & Finish

Description Material Finish
Body steel Nickel
Center  Contact Pin High temperature thermoplastic ——
Insulator Copper Alloy ——
