TNC Male Connector RG58 Straight Solder Type for Cable RG59

Part No.: RHT-615-0007

Tags：Panel Mount,Jack/female, Straight/180°, 50Ω, Solder Type,bulkhead

Features:
  • 12 Months’ Quality Insurance;
  • FREE sample available for quality test;
  • Can be Customized for unique material or performance requirement;
  • Thread Version of BNC used in Vibration-Intense application with high durability;
  • Higher Performance than BNC with 0-11 GHz Microwave frequencies and 50 Ω impedance;
  • High cost-effective with good quality according to MIL-C-39012.
Ask a quote

Technical Characteristics

Temperature Range -55°C to 155°C
Vibration 100m/S2 (10 to 2000 Hz) 15g
Impendance 50Ω
Frenquency Range DC-11GHZ
Working Voltage 500V r.m.s at sea level
Workstandinging Voltage 1500V r.m.s at sea level
Center Contact Resistance ≦10mΩ
Outer Contact Resistance ≦2.5mΩ
Insulation Resistance ≧5000MΩ
Center conductor Retention Force ≦0.57N
Insertion Loss ≤0.20dB
VSWR Straight ≤1.22/3GHz
VSWR Right Angle ≤1.30/3GHz
Durability (Mating) ≧500(cycles)

VSWR: Voltage Standing Wave Ratio

Material & Finish

Description Material Finish
Body Brass Nickel
Contact Pin Brass Gold
Insulator Teflon White
