USB 3.0AF Short Type 90 Degree PA9T Blue Rubber Core 13.7mm

Part No.:RHT-692-1393

Tags:Type A,USB3.0,female,right angle,9,through hole,pcb mount


  • Type B,USB3.0,male,Straight,9p,pcb,solder type;
  • Capable of transferring data up to 5Gb/s;
  • Full metal shielding;
  • High Quality with 30 days 100% Money back;
  • From the OEM Original Factory, same quality with much better price.

Technical Characteristics

Contact Resistance 30Ω Maximum
Contact Current Rating 1.50A
Dielectric Withstanding Voltage 100V R.M.S
Insulation Resistance 1000 Megohms Min
Operating Temperoture -45°C ~ +80°C
Mating Force 3.57kg Max
Unmating Force 1.02kg Min
Operating Temperature -45°C~ + 85°C

VSWR: Voltagge Standing Wave Ratio

Material & Finish

Part Material Finish
Housing High Temperature Polymer UL94V-0, Black
Shell Stainless Steel ——
Contact Copper Alloy ——
