Products > Sensor Connector > M8 Series > M8 5 Pin Female Straight Field Assembly Plug, B Code Shielded, Solder Cup
- Technical data
- Overview
- Certification
- Download
| General | |
|---|---|
| Connector Type | Plug |
| Number of Positions | 5 |
| Contact Type | Female Pin |
| Key | B |
| Orientation | Straight |
| Shell Size | M8 |
| Mounting Type | Cable Type |
| Fastening Type | Threaded |
| Contact Termination | Solder Cup |
| Materials | |
|---|---|
| Shell Material | Copper Alloy |
| Shell Finish | Zinc Plated |
| Contact Material | Copper Alloy |
| Contact Finish | Gold |
| Electrical | |
|---|---|
| Rated Voltage | 60V |
| Rated Current | 3A |
| Shielding | Shielded |
| Environmental | |
|---|---|
| Ingress Protection | IP67 |
| Operating Temperature | -25°C ~ + 85°C |
Product certification
Product excerpt
- 5 Pins (B-Coded): Designed for precise alignment and secure connections in industrial data networks.
- Shielded Design: Protects against electromagnetic interference (EMI) to ensure stable and reliable performance.
- Field Wireable: Allows for on-site assembly, accommodating custom cable lengths.
- Solder Cup Contacts: Provides a secure connection through soldering, ensuring durability.
- Straight Orientation: Ideal for easy cable routing in confined spaces.
