BNC Connector

BNC connectors use a bayonet locking structure, with characteristic impedances of 50Ω and 75Ω, a typical operating frequency of ≤4GHz, low insertion loss and small standing wave ratio, and good electromagnetic shielding performance. They are widely used in communication networks, audio and video broadcasting, test and measurement, and industry. RENHOTEC RF provides a full range of BNC connectors, including standard BNC, precision BNC, waterproof BNC, and micro BNC.

BNC Connector Solutions from Renhotec

TOTAL 90 SERIES & PRODUCTS

Product Benefits

  • Excellent anti-vibration performance, suitable for high vibration environment
  • High frequency and low loss transmission
  • Minimal signal reflection, reducing energy loss
  • Small size, high space utilization, suitable for micro devices
  • Strong environmental adaptability, suitable for long-term outdoor use

Product Features

  • Clip-on locking structure, double guide pin slots
  • Threaded precision connection structure
  • Broadband high frequency characteristics
  • 50Ω standard impedance consistency
  • Miniaturized and compact design
  • Highly durable metal housing

Applications

  • Wireless Communication：Base stations, telecom networks, antenna systems
  • Testing Instruments：RF test equipment, spectrum/network analyzers
  • Satellite Communication：Satellite receivers, ground station RF links
  • Medical Equipment：RF therapeutic devices, microwave medical equipment
  • Automotive Electronics：Vehicle radar, intelligent driving sensors
  • Computer & Network：PC RF modules, LAN wireless devices

How Can We Help You?

If you have any specific needs or ideas, our development and design team is here to help. We're ready to collaborate with you to create a connector system tailored to your unique requirements. Whether you’re looking for a custom solution or simply have questions, don't hesitate to reach out.

Whether you’re looking for a custom solution or simply have questions

Just Contact us!

[email protected]
+86-180-8661-0187

More about BNC Coaxial Connector

Yes, HD-BNC connectors provide higher clarity and better performance. HD-SDI also includes Mini SDI, which is smaller in size and can save space.

50-ohm BNC connectors are the most common and are suitable for most general applications, typically used in high-frequency ranges. 75-ohm BNC connectors usually provide better performance in lower frequency ranges, such as in television broadcasting and radio frequency spectrum analysis.

Ensure that the connector is fully inserted and locked by rotating it. Make sure the connection point is clean, free from dirt or oxidation, and use high-quality connectors and appropriate tools.

Nickel-plated BNC connectors are widely used in various general environments. They offer good cost-effectiveness, excellent corrosion resistance, and durability, but have higher signal loss in high-frequency applications compared to gold-plated ones. Gold-plated BNC connectors have superior conductivity and oxidation resistance, but are more expensive.

Brass: Excellent conductivity, corrosion resistance, durability, and ease of machining. Costs slightly higher than zinc alloy. Zinc Alloy: Lightweight and cost-effective. Conductivity and corrosion resistance are slightly lower than brass. For harsh environments, brass BNC connectors are recommended.
