TNC Connector

The TNC connector series is a miniature, threaded weatherproof series with a constant 50 Ω impedance and a frequency range of DC to 11 GHz. The TNC series shares its contact design with the BNC series, utilizing a threaded coupling nut for secure mating and higher frequency performance than the BNC. TNC connectors are produced with standard and reverse polarity. Reverse polarity is a keying system accomplished with a reverse interface, and ensures that reverse polarity interface connectors do not mate with standard interface connectors. Amphenol accomplishes this by inserting female contacts into plugs and male contacts into jacks to ensure quality. Other manufacturers may use reverse threading to accomplish reverse polarity keying. As a result of their versatility and durability, TNC connectors are ideal for a variety applications.

TNC Connector Solutions from Renhotec

TOTAL 75 SERIES & PRODUCTS

Product Benefits

  • Excellent electrical performance, can ensure the accuracy and precision of signal transmission
  • Reliable mechanical performance, stable and shock-resistant
  • Strong environmental adaptability, can be widely used in various harsh outdoor application scenarios
  • Good compatibility, a variety of models and sizes are available

Product Features

  • Polarity options: Standard polarity TNC connector and Reverse polarity TNC connector (RP-TNC)
  • 50 Ω standard characteristic impedance
  • Threaded locking structure for more stable connection

Applications

  • Cellular Mobile Phones
  • Aviation Controls
  • GPS, Wireless Base Station
  • Microwave Components
  • Radar, Telemetry, Networks
  • Antenna Mounts
  • Machine to machine communications
  • Security Devices, Instrumentation, etc…

How Can We Help You?

If you have any specific needs or ideas, our development and design team is here to help. We're ready to collaborate with you to create a connector system tailored to your unique requirements. Whether you’re looking for a custom solution or simply have questions, don't hesitate to reach out.

Whether you’re looking for a custom solution or simply have questions

Just Contact us!

[email protected]
+86-180-8661-0187

More about TNC Coaxial Connector

TNC (Threaded type) is an upgraded version of BNC. It provides more stable anti-vibration performance through the threaded mechanism and can operate at a maximum frequency of up to 11GHz.

The core difference lies in the connection method: BNC: Snap-on type (Quick plug and unplug) TNC: Threaded type (Stronger vibration resistance) → Applicable scenarios: TNC is a must-have for vibration environments (such as vehicle-mounted and airborne)

The standard TNC is not waterproof, but the TNC-IP67 model (with rubber sealing ring) is optional and can withstand temporary immersion in water (1 meter deep for 30 minutes).

Match according to the demand: Shell: Nickel-plated brass (standard)/Stainless steel (corrosion-resistant) Contacts: Gold-plated (high frequency and low loss)/Silver-plated (low cost) Insulator: PTFE (High-temperature resistant to 260℃)
