Products > Push-Pull Connector > B Series Push Pull Self-locking Connector Socket Female Straight EGG 1B 305 CLL Back Mount
- Overview
- Technical data
- Catalog
Find the B Series Push Pull Self-locking Connector Socket Female Straight EGG 1B 305 CLL Back Mount for seamless and secure electrical connections. Designed for easy installation and reliable performance.
General
Connector Type | Socket |
Orientation | Straight |
Contact Type | Female Pin |
Number of Positions | 5 |
Shell
Shell Size | M12 |
Mechanical
Fastening Type | Snap on |
Mounting Type | Panel Mount |
Wire Gauge or Range | 30-22AWG |
Mounting Feature | Bulkhead - Rear Fastened |
Material
Shell Material | Copper Alloy |
Contact Material | Copper Alloy |
Contact Finish | Gold |
Insulating Material | PPS |
Electrical
Shielding | Shielded |
Rated Current | 9A |
Environmental
Operating Temperature | -55°C ~ + 150°C |
RENHOTEC Push-Pull Self-Locking Connetor [EN] | Download |
