Coaxial Connector SMA Right Angle Jack Female Pin Panel Mount SMT 50 Ohm - DS806MCS118
Coaxial Connector SMA Right Angle Jack Female Pin Panel Mount SMT 50 Ohm - DS806MCS118
Coaxial Connector SMA Right Angle Jack Female Pin Panel Mount SMT 50 Ohm product image
Coaxial Connector SMA Right Angle Jack Female Pin Panel Mount SMT 50 Ohm product image
Coaxial Connector SMA Right Angle Jack Female Pin Panel Mount SMT 50 Ohm product image

DS806MCS118

Coaxial Connector SMA Right Angle Jack Female Pin Panel Mount SMT 50 Ohm

  • Technical data
  • Overview
  • Certification
  • Download
General
Connector TypeMale
Number of Ports1
Contact TypeMale Pin
OrientationStraight
Mounting TypeCable Type
Fastening TypeThreaded
TerminationCrimp
Suitable CableRG8
Feature-
Materials
Body MaterialCopper Alloy
PlatingNickel Plated
Contact MaterialPhosphor Bronze
Contact PlatingGold
Electrical
Impedance50 Ohms
Frequency(max)6GHz

Product excerpt

SMA right angle jack female pin panel mount SMT coaxial connector with 50 Ohm impedance. Contact us for a quote on DS806MCS118, ideal for custom B2B applications.
