M5 4 Pin Male Right Angled Panel Mounting Receptacle, A code Unshielded - RHT-634-1411-04
M5 4 Pin Male Right Angled Panel Mounting Receptacle, A code Unshielded - RHT-634-1411-04
M5 4 Pin Male Right Angled Panel Mounting Receptacle, A code Unshielded product image

RHT-634-1411-04

M5 4 Pin Male Right Angled Panel Mounting Receptacle, A code Unshielded

  • Technical data
  • Overview
  • Certification
  • Download
General
Connector TypeReceptacle
Number of Positions4
Contact TypeMale Pin
KeyA
OrientationRight Angle
Shell SizeM5
Mounting TypePanel Mount
Fastening TypeThreaded
Contact TerminationThrough Hole
Materials
Shell MaterialCopper Alloy
Shell FinishZinc Plated
Contact MaterialCopper Alloy
Contact FinishGold
Electrical
Rated Voltage60V
Rated Current1A
ShieldingUnshielded
Environmental
Ingress ProtectionIP67
Operating Temperature-25°C ~ + 85°C

Product excerpt

  1. M5 male panel mounting receptacle with 4 positions (A code)
  2. Unshielded design for compact setups
  3. Right-angled configuration for space-constrained installations
  4. Rear fastened for stable and reliable connections
  5. Suitable for industrial and automation applications

Catelog

RENHOTEC M-Series Connector Catalog [EN][CN] Download
Drawing for M5 Male Panel Mounting Receptacle Unshielded Right Angled Download
