MS3112E10-6S/PT02E-10-6S

MIL-DTL-26482 Connector MS3112E10-6S Female Box Mount Receptacle 6 Pin
Get a Quote
Products >
  • Overview
  • Technical data
  • Certification
  • Download

Product excerpt

High-quality MIL-DTL-26482 connector featuring a MS3112E10-6S female box mount receptacle with 6 pins. Ideal for secure and reliable electrical connections.
GeneralMaterialMechanicalEnvironmentalShellElectrical
General
Connector TypeReceptacle
OrientationStraight
Contact TypeFemale Pin
Number of Positions6
Contact Arrangements10-6
Contact TerminationSolder Cup
ColorOlive Green
Material
Shell MaterialAluminum Alloy
Contact FinishGold
Insulating MaterialSynthetic Rubber
Contact MaterialCopper Alloy
Mechanical
Fastening TypeBayonet
Mounting TypePanel Mount
Mounting FeatureFlange
Wire Gauge or RangeAWG24，22，20
Environmental
Operating Temperature-55°C ~ + 125°C
Shell
Shell Size10
Electrical
ShieldingUnshielded
Rated Current7.5A
Rated Voltage600V
