Products > MIL Spec Connector > MIL-DTL-26482 Connector MS3112E12-3P Male Box Mount Receptacle 3 Pin

MS3112E12-3P/PT02E-12-3P
MIL-DTL-26482 Connector MS3112E12-3P Male Box Mount Receptacle 3 Pin

Compare

Product Type

Only 4 products can be compared at a time. Please select the product you want to replace.

    • Overview
    • Technical data
    • Catalog

    Connect various components with this 3-pin male box mount receptacle MIL-DTL-26482 connector. Ideal for industrial applications.

    1. General
    2. Shell
    3. Mechanical
    4. Material
    5. Electrical
    6. Environmental

    General

    Connector TypeReceptacle
    OrientationStraight
    Contact TypeMale Pin
    Number of Positions3
    Contact Arrangements12-3
    Contact TerminationSolder Cup
    ColorBlack

    Shell

    Shell Size12

    Mechanical

    Fastening TypeBayonet
    Mounting TypePanel Mount
    Mounting FeatureFlange
    Wire Gauge or RangeAWG20，18，16

    Material

    Shell MaterialAluminum Alloy
    Contact FinishGold
    Insulating MaterialSynthetic Rubber
    Contact MaterialCopper Alloy

    Electrical

    ShieldingUnshielded
    Rated Current22A
    Rated Voltage1275VDC

    Environmental

    Operating Temperature-55°C ~ + 125°C
