Products > MIL Spec Connector > MIL-DTL-26482 Connector MS3112E14-12S Female Box Mount Receptacle 12 Pin

MS3112E14-12S/PT02E-14-12S
MIL-DTL-26482 Connector MS3112E14-12S Female Box Mount Receptacle 12 Pin

Compare

Product Type

Only 4 products can be compared at a time. Please select the product you want to replace.

    • Overview
    • Technical data
    • Catalog

    High-quality MIL-DTL-26482 12-pin female box mount receptacle connector MS3112E14-12S. Ideal for secure and reliable connection in various applications.

    1. General
    2. Shell
    3. Mechanical
    4. Material
    5. Electrical
    6. Environmental

    General

    Connector TypeReceptacle
    OrientationStraight
    Contact TypeFemale Pin
    Number of Positions12
    Contact Arrangements14-12
    Contact TerminationSolder Cup
    ColorOlive Green

    Shell

    Shell Size14

    Mechanical

    Fastening TypeBayonet
    Mounting TypePanel Mount
    Mounting FeatureFlange
    Wire Gauge or Range8*AWG24，22，20/4*AWG20，18，16

    Material

    Shell MaterialAluminum Alloy
    Contact FinishGold
    Insulating MaterialSynthetic Rubber
    Contact MaterialCopper Alloy

    Electrical

    ShieldingUnshielded
    Rated Current4*22A/8*7.5A
    Rated Voltage600V

    Environmental

    Operating Temperature-55°C ~ + 125°C
