RHT-615-0437
Straight TNC Solder Panel Mount 50ohm- Overview
- Technical data
- Certification
- Download
Product excerpt
Straight TNC Solder Panel Mount connector, 50ohm impedance, suitable for high-reliability applications. Contact us for a quotation on SKU RHT-615-0437.
MechanicalGeneralElectricalMaterial
| Mechanical | |
|---|---|
| Fastening Type | Threaded |
| Termination | Solder |
| Mounting Type | Panel Mount |
| Mount Feature | Bulkhead |
| Suitable Cable | - |
| General | |
|---|---|
| Connector Type | Jack |
| Orientation | Straight |
| Contact Type | Female Pin |
| Number of Ports | 1 |
| Feature | - |
| Electrical | |
|---|---|
| Impedance | 50 Ohms |
| Frequency(max) | 6GHz |
| Material | |
|---|---|
| Body Material | Copper Alloy |
| Plating | Nickel Plated |
| Contact Material | Brass |
| Contact Plating | Gold |
