Products > Sensor Connector > M12 Series > M12 A Coded > M12 4 Pin Female Straight Panel Mount Receptacle, A Code Rear Fastened, PCB M15 ,Nylon Shell
M12 4 Pin Female Straight Panel Mount Receptacle, A Code Rear Fastened, PCB M15 ,Nylon Shell - RHT-634-3255-04
M12 4 Pin Female Straight Panel Mount Receptacle, A Code Rear Fastened, PCB M15 ,Nylon Shell - RHT-634-3255-04
M12 4 Pin Female Straight Panel Mount Receptacle, A Code Rear Fastened, PCB M15 ,Nylon Shell product image

RHT-634-3255-04

M12 4 Pin Female Straight Panel Mount Receptacle, A Code Rear Fastened, PCB M15 ,Nylon Shell

Number of Positions:

  • Technical data
  • Overview
  • Certification
  • Download
General
Connector TypeReceptacle
Number of Positions4
Contact TypeFemale Pin
KeyA
OrientationStraight
Shell SizeM12
Mounting TypePanel Mount
Mounting FeatureBulkhead - Rear Fastened
Fastening TypeThreaded
Contact TerminationThrough Hole
Materials
Shell MaterialNylon
Contact MaterialCopper Alloy
Contact FinishGold
Electrical
Rated Voltage250V
Rated Current4A
ShieldingUnshielded
Environmental
Ingress ProtectionIP67
Operating Temperature-25°C ~ + 85°C

Product certification

Product excerpt

Certification

Renhotec REACH Test Report Download

Catelog

RENHOTEC M-Series Connector Catalog [EN][CN] Download
