Products > Sensor Connector > M12 Series > M12 S Coded > M12 4 Pin(3+PE) Male Straight Panel Mount Receptacle, S Code Flange, Solder
M12 4 Pin(3+PE) Male Straight Panel Mount Receptacle, S Code Flange, Solder - RHT-634-3301-S-04
M12 4 Pin(3+PE) Male Straight Panel Mount Receptacle, S Code Flange, Solder - RHT-634-3301-S-04
M12 4 Pin(3+PE) Male Straight Panel Mount Receptacle, S Code Flange, Solder product image

RHT-634-3301-S-04

M12 4 Pin(3+PE) Male Straight Panel Mount Receptacle, S Code Flange, Solder

Number of Positions:

234

Complete the form below for a quick professional response. We guarantee to contact you within 24 hours.


    Get a Quote
    Products >
    • Technical data
    • Overview
    • Certification
    • Download
    GeneralMaterialsElectricalEnvironmental
    General
    Connector TypeReceptacle
    Number of Positions4
    Contact TypeMale Pin
    KeyS
    OrientationStraight
    Shell SizeM12
    Mounting TypePanel Mount
    Mounting FeatureFlange
    Fastening TypeThreaded
    Contact TerminationThrough Hole
    Materials
    Shell MaterialCopper Alloy
    Shell FinishNickel Plated
    Contact MaterialCopper Alloy
    Contact FinishGold
    Electrical
    Rated Voltage630V
    Rated Current12A
    ShieldingUnshielded
    Environmental
    Ingress ProtectionIP67
    Operating Temperature-20°C ~ + 80°C

    Product certification

    ×

    Product excerpt

    Certification

    Renhotec REACH Test Report Download

    Catelog

    RENHOTEC M-Series Connector Catalog [EN][CN] Download
