M5 4 Pin Male Straight Panel Mount Receptacle, A code Unshielded, Rear Fastened PCB - M5004-04
M5 4 Pin Male Straight Panel Mount Receptacle, A code Unshielded, Rear Fastened PCB - M5004-04
M5 4 Pin Male Straight Panel Mount Receptacle, A code Unshielded, Rear Fastened PCB product image

M5004-04

M5 4 Pin Male Straight Panel Mount Receptacle, A code Unshielded, Rear Fastened PCB

Number of Positions:

34

Complete the form below for a quick professional response. We guarantee to contact you within 24 hours.


    Get a Quote
    Products >
    • Technical data
    • Overview
    • Certification
    • Download
    GeneralMaterialsElectricalEnvironmental
    General
    Connector TypeReceptacle
    Number of Positions4
    Contact TypeMale Pin
    KeyA
    OrientationStraight
    Shell SizeM5
    Mounting TypePanel Mount
    Fastening TypeThreaded
    Contact TerminationThrough Hole
    Materials
    Shell MaterialCopper Alloy
    Shell FinishZinc Plated
    Contact MaterialCopper Alloy
    Contact FinishGold
    Electrical
    Rated Voltage60V
    Rated Current1A
    ShieldingUnshielded
    Environmental
    Ingress ProtectionIP67
    Operating Temperature-25°C ~ + 85°C

    Product excerpt

    1. M5 male panel mounting receptacle with 4 positions (A code)
    2. Unshielded design for standard electrical connections
    3. Straight PCB mount for easy integration onto circuit boards
    4. Compact and durable, suitable for industrial applications
    5. Reliable performance in various environmental conditions

    Catelog

    RENHOTEC M-Series Connector Catalog [EN][CN] Download
    Drawing for M5 Male Panel Mounting Receptacle Unshielded Straight PCB Mount Download
