product image

M5001-03

M5 3 Pin Male Straight Panel Mount Receptacle, A code Unshielded, Rear Fastened Solder Cup

Color:

Silver

Number of Positions:

  • Overview
  • Technical data
  • Certification
  • Download

Product excerpt

  1. M5 male panel mounting receptacle with 3 positions
  2. A-code for secure and reliable data connections
  3. Unshielded design for standard applications
  4. Rear fastened for easy and secure installation
  5. Solder cup termination for efficient wiring
EnvironmentalElectricalMaterialGeneralMechanicalShell
Environmental
Ingress ProtectionIP67
Electrical
Rated Current1A
Material
Shell MaterialCopper Alloy
General
Connector TypeReceptacle
Mechanical
Fastening TypeThreaded
Shell
Shell SizeM5

Catelog

RENHOTEC M-Series Connector Catalog [EN][CN] Download
Drawing for M5 Male Panel Mounting Receptacle Unshielded Rear Fastened Solder Cup Download
