product image

RHT-634-1278-04

M8 Female Field Wireable Plug 4 Pin A Code Unshielded Right Angle Solder Cup

Color:

Black

Number of Positions:

3456
Get a Quote
Products >
  • Overview
  • Technical data
  • Certification
  • Download

Product certification

×

Product excerpt

  1. 4 Pins (A-Coded): Provides secure and precise connections for multiple signal or power applications.
  2. Unshielded Design: Suitable for environments with minimal electromagnetic interference (EMI).
  3. Right Angle Orientation: Facilitates efficient cable routing in compact or confined spaces.
  4. Solder Cup Contacts: Ensures a robust and reliable connection through soldering.
GeneralMaterialMechanicalEnvironmentalShellElectrical
General
Connector TypePlug
OrientationRight Angle
Contact TypeFemale Pin
Number of Positions4
KeyA
Contact TerminationSolder Cup
Material
Shell MaterialPA66+GF
Contact FinishGold
Contact MaterialCopper Alloy
Mechanical
Fastening TypeThreaded
Mounting TypeCable Type
Environmental
Ingress ProtectionIP67
Operating Temperature-25°C ~ + 85°C
Shell
Shell SizeM8
Electrical
ShieldingUnshielded
Rated Current3A
Rated Voltage30V

Certification

M8 M12 M16 Connector AGC07686211202-002 REACH Download
Drawing for M8 Female Field Wireable Plug Unshielded Right Angle Solder Cup Download
