product image

RHT-634-3282-03

M8 3 Pin Female Right Angle Panel Mount Receptacle, B Code Shielded, PCB Solder

Number of Positions:

  • Overview
  • Technical data
  • Certification
  • Download

Product certification

Product excerpt

  1. M8 3-pin female panel mount with A code and right-angle PCB design
  2. Shielded for excellent EMI/RFI protection, ensuring reliable signal transmission
  3. Ideal for use in automation, sensors, and industrial control applications
  4. Space-saving right-angle design for compact installations on PCB
  5. Durable construction for long-term performance in harsh environments
EnvironmentalElectricalMaterialGeneralMechanicalShell
Environmental
Ingress ProtectionIP67
Electrical
Rated Current3A
Material
Shell MaterialCopper Alloy
General
Connector TypeReceptacle
Mechanical
Fastening TypeThreaded
Shell
Shell SizeM8

Certification

Renhotec REACH Test Report Download

Catelog

RENHOTEC M-Series Connector Catalog [EN][CN] Download
Drawing for M8 Female Panel Mount Receptacle Shielded Right Angle PCB Download
