Products > Circular Connector > M8 Female Panel Mount Receptacle 3 Pin A Code Unshielded Right Angle PCB

RHT-634-1204
M8 Female Panel Mount Receptacle 3 Pin A Code Unshielded Right Angle PCB

Compare

Product Type

Only 4 products can be compared at a time. Please select the product you want to replace.

    • Overview
    • Technical data
    • Catalog
    • Certificate

    Product certification

    ×

    This M8 female panel mount receptacle features 3 pins, A code configuration, and is unshielded with a right angle PCB design. Perfect for securely attaching and connecting components.

    1. General
    2. Shell
    3. Mechanical
    4. Material
    5. Environmental
    6. Electrical

    General

    Connector TypeReceptacle
    OrientationRight Angle
    Contact TypeFemale Pin
    Number of Positions3
    KeyA
    Contact TerminationThrough Hole

    Shell

    Shell SizeM8

    Mechanical

    Fastening TypeThreaded
    Mounting TypePanel Mount
    Mounting FeatureBulkhead

    Material

    Shell MaterialPA66+GF
    Contact FinishGold
    Contact MaterialCopper Alloy

    Environmental

    Ingress ProtectionIP67
    Operating Temperature-25°C ~ + 85°C

    Electrical

    ShieldingUnshielded
    Rated Current3A
    Rated Voltage60V
