Products > Sensor Connector > M8 Series > M8 4 Pin Female Straight Panel Mount Receptacle, A Code Front Fastened, PCB Solder, M12x1
- Technical data
- Overview
- Certification
- Download
| General | |
|---|---|
| Connector Type | Receptacle |
| Number of Positions | 4 |
| Contact Type | Female Pin |
| Key | A |
| Orientation | Straight |
| Shell Size | M8 |
| Mounting Type | Panel Mount |
| Mounting Feature | Bulkhead |
| Fastening Type | Threaded |
| Contact Termination | Through Hole |
| Materials | |
|---|---|
| Shell Material | Copper Alloy |
| Shell Finish | Zinc Plated |
| Contact Material | Copper Alloy |
| Contact Finish | Gold |
| Electrical | |
|---|---|
| Rated Voltage | 60V |
| Rated Current | 3A |
| Shielding | Unshielded |
| Environmental | |
|---|---|
| Ingress Protection | IP67 |
| Operating Temperature | -25°C ~ + 85°C |
Product certification
Product excerpt
- 4 Pins (A-Coded): Provides secure, precise connections.
- A-Coded: Ensures correct orientation and compatibility.
- Front Fastened: Attaches securely to the panel from the front side.
- Straight Orientation: Facilitates direct mounting on PCB (Printed Circuit Board).
- Open Hole Design: Allows for versatile mounting and connections.
