product image

RHT-634-1298-04

M8 4 Pin Female Straight Panel Mount Receptacle, A Code Rear Fastened, Solder Cup M8

Number of Positions:

34568

Complete the form below for a quick professional response. We guarantee to contact you within 24 hours.


    Get a Quote
    Products >
    • Overview
    • Technical data
    • Certification
    • Download

    Product certification

    ×

    Product excerpt

    1. 4 Pins (A-Coded): Provides secure, precise connections.
    2. A-Coded: Ensures correct orientation and compatibility.
    3. Rear Fastened: Secures attachment to the panel from the rear side.
    4. Straight Orientation: Facilitates direct mounting on PCB (Printed Circuit Board).
    5. Solder Cup Contacts: Ensures robust, reliable connections through soldering.
    EnvironmentalElectricalMaterialGeneralMechanicalShell
    Environmental
    Ingress ProtectionIP67
    Electrical
    Rated Current3A
    Material
    Shell MaterialCopper Alloy
    General
    Connector TypeReceptacle
    Mechanical
    Fastening TypeThreaded
    Shell
    Shell SizeM8

    Certification

    Renhotec REACH Test Report Download

    Catelog

    RENHOTEC M-Series Connector Catalog [EN][CN] Download
    Drawing for M8 Female Panel Mount Receptacle Rear Fastened Straight Solder Cup Download
