Products > Circular Connector > M8 Female Panel Mount Receptacle 6 Pin A Code Front Fastened Straight PCB M12

RHT-634-1201-06
M8 Female Panel Mount Receptacle 6 Pin A Code Front Fastened Straight PCB M12

Color
  1. Silver
Number of Positions
  1. 3
  2. 4
  3. 5
  4. 6
  5. 8
Compare

Product Type

Only 4 products can be compared at a time. Please select the product you want to replace.

    • Overview
    • Technical data
    • Catalog
    • Certificate

    Product certification

    ×

    This M8 female panel mount receptacle features 6 pins, A code front fastened design, and is straight PCB mounted. Perfect for secure and reliable connections in industrial applications.

    1. General
    2. Shell
    3. Mechanical
    4. Material
    5. Environmental
    6. Electrical

    General

    Connector TypeReceptacle
    OrientationStraight
    Contact TypeFemale Pin
    Number of Positions6
    KeyA
    Contact TerminationThrough Hole

    Shell

    Shell SizeM8

    Mechanical

    Fastening TypeThreaded
    Mounting TypePanel Mount
    Mounting FeatureBulkhead

    Material

    Shell MaterialCopper Alloy
    Shell FinishZinc Plated
    Contact FinishGold
    Contact MaterialCopper Alloy

    Environmental

    Ingress ProtectionIP67
    Operating Temperature-25°C ~ + 85°C

    Electrical

    ShieldingUnshielded
    Rated Current3A
    Rated Voltage60V
