Products > Circular Connector > M8 Male Field Wireable Plug 3 Pin A Code Unshielded Right Angle Screw Contacts
product image

RHT-634-1354-03

M8 Male Field Wireable Plug 3 Pin A Code Unshielded Right Angle Screw Contacts

Color:

Black

Number of Positions:

344
Get a Quote
Products >
  • Overview
  • Technical data
  • Certification
  • Download

Product certification

×

Product excerpt

  1. 3 Pins (A-Coded): Ensures proper alignment for signal or power connections.
  2. Unshielded Design: Suitable for environments with minimal EMI interference.
  3. Right Angle Orientation: Ideal for compact spaces and efficient cable routing.
  4. Screw Contacts: Provides a secure connection with easy assembly and adjustments.
GeneralMaterialMechanicalEnvironmentalShellElectrical
General
Connector TypePlug
OrientationRight Angle
Contact TypeMale Pin
Number of Positions3
KeyA
Contact TerminationOuter Screw
Material
Shell MaterialPA66+GF
Contact FinishGold
Contact MaterialCopper Alloy
Mechanical
Fastening TypeThreaded
Mounting TypeCable Type
Environmental
Ingress ProtectionIP67
Operating Temperature-25°C ~ + 85°C
Shell
Shell SizeM8
Electrical
ShieldingUnshielded
Rated Current3A
Rated Voltage60V

Certification

M8 M12 M16 Connector AGC07686211202-002 REACH Download
Drawing for M8 Male Field Wireable Plug A Code Unshielded Right Angle Screw Contacts Download

Catelog

RENHOTEC M-Series Connector Catalog [EN][CN] Download
