Products > Sensor Connector > M8 Series > M8 5 Pin Male Straight Field Assembly Plug, B Code Unshielded, Solder Cup
- Technical data
- Overview
- Certification
- Download
| General | |
|---|---|
| Connector Type | Plug |
| Number of Positions | 5 |
| Contact Type | Male Pin |
| Key | B |
| Orientation | Straight |
| Shell Size | M8 |
| Mounting Type | Cable Type |
| Fastening Type | Threaded |
| Contact Termination | Solder |
| Materials | |
|---|---|
| Shell Material | PA66+GF |
| Contact Material | Copper Alloy |
| Contact Finish | Gold |
| Electrical | |
|---|---|
| Rated Voltage | 30V |
| Rated Current | 3A |
| Shielding | Unshielded |
| Environmental | |
|---|---|
| Ingress Protection | IP67 |
| Operating Temperature | -25°C ~ + 85°C |
Product certification
Product excerpt
- 5 Pins (B-Coded): Provides accurate alignment for multiple signal or power connections.
- Unshielded Design: Suitable for environments with minimal EMI interference.
- Straight Orientation: Facilitates straightforward cable routing.
- Solder Contacts: Ensures a reliable and durable connection through soldering.
