RHT-634-1300-05
M8 Male Panel Mount Receptacle 5 Pin B Code Front Fastened Straight Solder Cup M8

Securely mount and connect your devices with this M8 male panel mount receptacle featuring 5 pins in B code configuration. The front fastened straight solder cup design ensures a reliable connection for your electronic applications.

Color
  1. Silver
Number of Positions
  1. 3
  2. 4
  3. 5
  4. 6
  5. 8
Compare

Product Type

Only 4 products can be compared at a time. Please select the product you want to replace.

    • Overview
    • Technical data
    • Catalog
    • Certificate

    Product certification

    1. General
    2. Shell
    3. Material
    4. Environmental
    5. Electrical

    General

    Connector TypeReceptacle
    OrientationStraight
    Contact TypeMale Pin
    Number of Positions5
    Fastening TypeThreaded
    Mounting TypePanel Mount
    Mounting FeatureBulkhead
    KeyB
    Contact TerminationSolder

    Shell

    Shell SizeM8

    Material

    Shell MaterialCopper Alloy
    Shell FinishZinc Plated
    Contact FinishGold
    Contact MaterialCopper Alloy

    Environmental

    Ingress ProtectionIP67
    Operating Temperature-25°C ~ + 85°C

    Electrical

    ShieldingUnshielded
    Rated Current3A
    Rated Voltage60V
