Products > Sensor Connector > M9 Female Panel Mounting Receptacle 3 Pin Front Fastened Straight Solder

RHT-634-3178-03
M9 Female Panel Mounting Receptacle 3 Pin Front Fastened Straight Solder

Get a secure and reliable connection with this M9 female panel mounting receptacle. This 3-pin receptacle is front fastened and designed for straight soldering, making it a convenient choice for your electronic projects.

Color
  1. Silver
Number of Positions
  1. 2
  2. 3
  3. 4
  4. 5
  5. 6
  6. 7
  7. 8
Compare

Product Type

Only 4 products can be compared at a time. Please select the product you want to replace.

    • Overview
    • Technical data
    • Catalog
    • Certificate

    Product certification

    1. General
    2. Shell
    3. Material
    4. Environmental
    5. Electrical

    General

    Connector TypeReceptacle
    OrientationStraight
    Contact TypeFemale Pin
    Number of Positions3
    Fastening TypeThreaded
    Mounting TypePanel Mount
    Contact TerminationSolder Cup

    Shell

    Shell SizeM9

    Material

    Shell MaterialCopper Alloy
    Shell FinishZinc Plated
    Contact FinishGold
    Contact MaterialCopper Alloy

    Environmental

    Ingress ProtectionIP67
    Operating Temperature-25°C ~ + 85°C

    Electrical

    ShieldingUnshielded
    Rated Current1A
    Rated Voltage125V
    Каталог разъемов RENHOTEC 2PM [EN][RU] Download
    RENHOTEC M-Series Connector Catalog [EN][CN] Download
