M9 5 Pin Male Straight Panel Mounting Receptacle, Front Fastened PCB - RHT-634-3258-05
M9 5 Pin Male Straight Panel Mounting Receptacle, Front Fastened PCB - RHT-634-3258-05
M9 5 Pin Male Straight Panel Mounting Receptacle, Front Fastened PCB product image

RHT-634-3258-05

M9 5 Pin Male Straight Panel Mounting Receptacle, Front Fastened PCB

Number of Positions:

  • Technical data
  • Overview
  • Certification
  • Download
General
Connector TypeReceptacle
Number of Positions5
Contact TypeMale Pin
OrientationStraight
Shell SizeM9
Mounting TypePanel Mount
Fastening TypeThreaded
Contact TerminationThrough Hole
Materials
Shell MaterialCopper Alloy
Shell FinishZinc Plated
Contact MaterialCopper Alloy
Contact FinishGold
Electrical
Rated Voltage125V
Rated Current1A
ShieldingUnshielded
Environmental
Ingress ProtectionIP67
Operating Temperature-25°C ~ + 85°C

Product excerpt

Securely mount your M9 male panel receptacle with this 5-pin front fastened straight PCB connector, ideal for various electronic applications.

Catelog

RENHOTEC M-Series Connector Catalog [EN][CN] Download
