Products > Circular Connector > M9 Male Panel Mounting Receptacle 6 Pin Rear Fastened Straight Solder
- Overview
- Technical data
- Catalog
This M9 male panel mounting receptacle features 6 pins, rear fastening, and a straight solder connection. Ideal for secure and reliable electrical connections in various applications.
General
Connector Type | Receptacle |
Orientation | Straight |
Contact Type | Male Pin |
Number of Positions | 6 |
Contact Termination | Solder Cup |
Shell
Shell Size | M9 |
Mechanical
Fastening Type | Threaded |
Mounting Type | Panel Mount |
Material
Shell Material | Copper Alloy |
Shell Finish | Zinc Plated |
Contact Finish | Gold |
Contact Material | Copper Alloy |
Environmental
Ingress Protection | IP67 |
Operating Temperature | -25°C ~ + 85°C |
Electrical
Shielding | Unshielded |
Rated Current | 1A |
Rated Voltage | 125V |
