Mini Change 7/8" 3 Pin Male Straight Panel Mount Receptacle, PG13.5 Unshielded, Rear Fastened Solder - 78005-03-PG13.5
Mini Change 7/8" 3 Pin Male Straight Panel Mount Receptacle, PG13.5 Unshielded, Rear Fastened Solder - 78005-03-PG13.5
Mini Change 7/8" 3 Pin Male Straight Panel Mount Receptacle, PG13.5 Unshielded, Rear Fastened Solder product image

78005-03-PG13.5

Mini Change 7/8" 3 Pin Male Straight Panel Mount Receptacle, PG13.5 Unshielded, Rear Fastened Solder

Number of Positions:

345

Complete the form below for a quick professional response. We guarantee to contact you within 24 hours.


    Get a Quote
    Products >
    • Technical data
    • Overview
    • Certification
    • Download
    GeneralMaterialsElectricalEnvironmental
    General
    Connector TypeReceptacle
    Number of Positions3
    Contact TypeMale Pin
    OrientationStraight
    Mounting TypePanel Mount
    Mounting FeatureBulkhead - Rear Fastened
    Fastening TypeThreaded
    Contact TerminationSolder
    Wire Gauge or Range6~8mm
    ColorSilver
    Materials
    Shell MaterialCopper Alloy
    Shell FinishZinc Plated
    Contact MaterialCopper Alloy
    Contact FinishGold
    Electrical
    Rated Voltage300V
    Rated Current13A
    ShieldingUnshielded
    Environmental
    Ingress ProtectionIP67
    Operating Temperature-25°C ~ + 80°C

    Product excerpt

    1. 7/8" 3-pin male panel mount receptacle, rear fastened
    2. Unshielded design for general industrial use
    3. Solder terminals for reliable electrical connections
    4. Rear fastened for secure and clean panel installation
    5. Suitable for industrial automation and power systems

    Catelog

    RENHOTEC M-Series Connector Catalog [EN][CN] Download
    Drawing for Mini Change 7/8″ Male Straight Panel Mount Receptacle, Unshielded, Rear Fastened Solder Download
