Mini Change 7/8" 5 Pin Male Straight Panel Mount Receptacle, M20 Unshielded, Rear Fastened Through Hole - 78006-05-M20
Mini Change 7/8" 5 Pin Male Straight Panel Mount Receptacle, M20 Unshielded, Rear Fastened Through Hole - 78006-05-M20
Mini Change 7/8" 5 Pin Male Straight Panel Mount Receptacle, M20 Unshielded, Rear Fastened Through Hole product image

78006-05-M20

Mini Change 7/8" 5 Pin Male Straight Panel Mount Receptacle, M20 Unshielded, Rear Fastened Through Hole

Number of Positions:

345

Complete the form below for a quick professional response. We guarantee to contact you within 24 hours.


    Get a Quote
    Products >
    • Technical data
    • Overview
    • Certification
    • Download
    GeneralMaterialsElectricalEnvironmental
    General
    Connector TypeReceptacle
    Number of Positions5
    Contact TypeMale Pin
    OrientationStraight
    Mounting TypePanel Mount
    Mounting FeatureBulkhead - Rear Fastened
    Fastening TypeThreaded
    Contact TerminationThrough Hole
    Wire Gauge or Range6~8mm
    ColorSilver
    Materials
    Shell MaterialCopper Alloy
    Shell FinishZinc Plated
    Contact MaterialCopper Alloy
    Contact FinishGold
    Electrical
    Rated Voltage300V
    Rated Current9A
    ShieldingUnshielded
    Environmental
    Ingress ProtectionIP67
    Operating Temperature-25°C ~ + 80°C

    Product excerpt

    1. 7/8" male panel mount receptacle, 5-pin, unshielded
    2. Front fastened for quick and secure installation
    3. PCB solder straight design ensures stable connections
    4. Ideal for industrial automation and power distribution applications
    5. Built for durability in demanding environments

    Catelog

    RENHOTEC M-Series Connector Catalog [EN][CN] Download
    Drawing for Mini Change 7/8″ Male Straight Panel Mount Receptacle, Unshielded, Rear Fastened Through Hole Download
