Products > Energy Storage Connector > 12.0mm Power Entry Connector 250A Cable Plug Right Angled 70mm2 Unshielded Cable Orange

FCC1270-F1YR
12.0mm Power Entry Connector 250A Cable Plug Right Angled 70mm2 Unshielded Cable Orange

Enhance your power connections with this durable 12.0mm Power Entry Connector. Featuring a high capacity of 250A and a right-angled design, it is suitable for 70mm2 unshielded cables. Stand out with the vibrant orange color while ensuring reliable performance.

Compare

Product Type

Only 4 products can be compared at a time. Please select the product you want to replace.

    • Overview
    • Technical data
    • Catalog
    • Certificate

    Product certification

    1. General
    2. Electrical
    3. Material
    4. Environmental

    General

    Connector TypePlug
    OrientationRight Angle
    Number of Positions1
    Contact TerminationCrimp
    Mounting TypeCable Type
    ColorOrange

    Electrical

    Rated Voltage1000V
    Rated Current250A
    ShieldingUnshielded

    Material

    Shell MaterialNylon
    Contact MaterialT2
    Contact FinishSilver

    Environmental

    Ingress ProtectionIP54
    Operating Temperature-40°C ~ + 125°C
    FlammabilityUL94 V-0
