Products > Energy Storage Connector > 14.0mm Power Entry Connector 480A Receptacle Busbar Teminal(M10 screw) Orange W Key
- Overview
- Technical data
- Catalog
This Side Entry Plastic Power Connector features a 480A Receptacle with Busbar in vibrant Orange color and a convenient W Key design. The perfect solution for your power connection needs.
General
Connector Type | Receptacle |
Orientation | Straight |
Number of Positions | 1 |
Contact Size | 14mm |
Contact Termination | Busbar |
Key | W |
Color | Orange |
Electrical
Rated Voltage | 1500V |
Rated Current | 480A |
Shielding | Unshielded |
Mechanical
Mounting Type | Panel Mount |
Mounting Feature | Flange |
Material
Shell Material | Nylon |
Contact Material | T2 |
Contact Finish | Silver |
Environmental
Ingress Protection | IP67 |
Operating Temperature | -40°C ~ + 125°C |
Flammability | UL94 V-0 |
