ST532000-A

5 POS High Power Electric vehicle connector Socket 40A 6mm2 Shielded Cable A Key
Get a Quote
Products >
  • Overview
  • Technical data
  • Certification
  • Download

Product certification

×

Product excerpt

This electric vehicle connector socket with 40A capacity and shielded cable is perfect for high voltage power distribution, battery pack, motor controller, electric air conditioning, electric heater, and more. Ensure safe and efficient power connections with this essential component.
GeneralMaterialMechanicalEnvironmentalElectrical
General
Connector TypeReceptacle
OrientationStraight
Number of Positions5
Contact TerminationCrimp
KeyA
ColorOrange
FeaturesWaterproof
Material
Shell MaterialPA66+GF
Contact MaterialCopper Alloy
Contact FinishTin
Mechanical
Mounting TypePanel Mount
Mounting FeatureFour Flange
Wire Gauge or Range6mm²
Environmental
Ingress ProtectionIP67
Operating Temperature-40°C ~ + 125°C
FlammabilityUL94 V-0
Electrical
Rated Voltage800V
Rated Current40A
ShieldingShielded
