6.0mm Waterproof Battery Storage Connector Straight 100A Black 16mm² UnShielded Cable W Key

Compare

Product Type

Only 4 products can be compared at a time. Please select the product you want to replace.

    • Overview
    • Technical data
    • Catalog

    Ensure secure connections with this 6.0mm waterproof battery storage connector. Straight design, 100A capacity, black color, and 16mm² unshielded cable with a convenient key feature for easy operation.

    1. General
    2. Electrical
    3. Mechanical
    4. Material
    5. Environmental

    General

    Connector TypePlug
    OrientationStraight
    Number of Positions1
    Contact Size6mm
    Contact TerminationCrimp
    KeyW
    ColorBlack

    Electrical

    Rated Voltage1000V
    Rated Current100A
    ShieldingUnshielded

    Mechanical

    Mounting TypeCable Type
    Wire Gauge or Range16mm²

    Material

    Shell MaterialPA66
    Contact MaterialT2
    Contact FinishSilver

    Environmental

    Ingress ProtectionIP67
    Operating Temperature-40°C ~ + 125°C
    FlammabilityUL94 V-0
