Products > Energy Storage Connector > 6.0mm Waterproof Battery Storage Connector Straight 70A Black 10mm² UnShielded Cable W Key

FSP600160CW-10U0B2RH
6.0mm Waterproof Battery Storage Connector Straight 70A Black 10mm² UnShielded Cable W Key

Get reliable connectivity with this 6.0mm waterproof battery storage connector. Suitable for 70A, the black 10mm² unshielded cable is designed with a convenient key for easy handling. Ensure secure power delivery in any environment.

Compare

Product Type

Only 4 products can be compared at a time. Please select the product you want to replace.

    • Overview
    • Technical data
    • Catalog
    • Certificate

    Product certification

    1. General
    2. Electrical
    3. Mechanical
    4. Material
    5. Environmental

    General

    Connector TypePlug
    OrientationStraight
    Number of Positions1
    Contact Size6mm
    Contact TerminationCrimp
    Mounting TypeCable Type
    KeyW
    ColorBlack

    Electrical

    Rated Voltage1000V
    Rated Current70A
    ShieldingUnshielded

    Mechanical

    Wire Gauge or Range10mm²

    Material

    Shell MaterialPA66
    Contact MaterialT2
    Contact FinishSilver

    Environmental

    Ingress ProtectionIP67
    Operating Temperature-40°C ~ + 125°C
    FlammabilityUL94 V-0
