Products > Sensor Connector > M12 Series > M12 B Coded > M12 5 Pin Female Right Angle Field Assembly Plug, B Code Screw Contacts PG7
- Technical data
- Overview
- Certification
- Download
| General | |
|---|---|
| Connector Type | Plug |
| Number of Positions | 5 |
| Contact Type | Female Pin |
| Key | B |
| Orientation | Right Angle |
| Shell Size | M12 |
| Mounting Type | Cable Type |
| Fastening Type | Threaded |
| Contact Termination | Outer Screw |
| Materials | |
|---|---|
| Shell Material | PA66+GF |
| Contact Material | Copper Alloy |
| Contact Finish | Gold |
| Electrical | |
|---|---|
| Rated Voltage | 60V |
| Rated Current | 4A |
| Shielding | Unshielded |
| Environmental | |
|---|---|
| Ingress Protection | IP67 |
| Operating Temperature | -25°C ~ + 85°C |
Product certification
Product excerpt
- 5-pin M12 female right-angle field assembly plug
- B code for signal transmission in industrial applications
- Screw contacts for secure, reliable connections
- PG7 cable entry for flexible installation
- Compact and durable design for harsh environments
- Ideal for automation, control systems, and sensor applications
