M12 4 Pin Female Right Angle Field Assembly Plug, D Code Screw Contacts PG7 - RHT-634-3373-4D-PG7
M12 4 Pin Female Right Angle Field Assembly Plug, D Code Screw Contacts PG7 - RHT-634-3373-4D-PG7
M12 4 Pin Female Right Angle Field Assembly Plug, D Code Screw Contacts PG7 product image

RHT-634-3373-4D-PG7

M12 4 Pin Female Right Angle Field Assembly Plug, D Code Screw Contacts PG7

Number of Positions:

  • Technical data
  • Overview
  • Certification
  • Download
General
Connector TypePlug
Number of Positions4
Contact TypeFemale Pin
KeyD
OrientationRight Angle
Shell SizeM12
Mounting TypeCable Type
Fastening TypeThreaded
Contact TerminationOuter Screw
Materials
Shell MaterialPA66+GF
Contact MaterialCopper Alloy
Contact FinishGold
Electrical
Rated Voltage250V
Rated Current4A
ShieldingUnshielded
Environmental
Ingress ProtectionIP67
Operating Temperature-25°C ~ + 85°C

Product certification

Product excerpt

  1. 4-pin M12 female right-angle field assembly plug
  2. D code for high-speed data transmission
  3. Screw contacts for reliable and secure connections
  4. PG7 cable entry for flexible installation
  5. Compact, rugged design suitable for industrial applications
  6. Perfect for sensors, automation, and control systems

Certification

Renhotec REACH Test Report Download

Catelog

RENHOTEC M-Series Connector Catalog [EN][CN] Download
