M5 4 Pin Female Panel Mount Receptacle, A code Unshielded, Front Fastened PCB - M5006-04
M5 4 Pin Female Panel Mount Receptacle, A code Unshielded, Front Fastened PCB - M5006-04
M5 4 Pin Female Panel Mount Receptacle, A code Unshielded, Front Fastened PCB product image

M5006-04

M5 4 Pin Female Panel Mount Receptacle, A code Unshielded, Front Fastened PCB

Number of Positions:

  • Technical data
  • Overview
  • Certification
  • Download
General
Connector TypeReceptacle
Number of Positions4
Contact TypeFemale Pin
KeyA
OrientationStraight
Shell SizeM5
Mounting TypePanel Mount
Fastening TypeThreaded
Contact TerminationThrough Hole
Materials
Shell MaterialCopper Alloy
Shell FinishZinc Plated
Contact MaterialCopper Alloy
Contact FinishGold
Electrical
Rated Voltage60V
Rated Current1A
ShieldingUnshielded
Environmental
Ingress ProtectionIP67
Operating Temperature-25°C ~ + 85°C

Product excerpt

  1. M5 female panel mounting receptacle with 4 positions (A code)
  2. Unshielded for simplified design and cost-efficiency
  3. Front fastened for easy installation
  4. PCB termination for stable and reliable connections
  5. Ideal for industrial automation and sensor applications

Catelog

RENHOTEC M-Series Connector Catalog [EN][CN] Download
Drawing for M5 Female Panel Mounting Receptacle Unshielded Front Fastened PCB Download
