Products > Circular Connector > M8 Female Field Wireable Plug 5 Pos B Code Unshielded Straight Solder
product image

RHT-634-3231-05

M8 Female Field Wireable Plug 5 Pos B Code Unshielded Straight Solder

Color:

Black

Number of Positions:

34568
Get a Quote
Products >
  • Overview
  • Technical data
  • Certification
  • Download

Product certification

×

Product excerpt

  1. 5 Pins (B-Coded): Provides precise alignment for secure data and signal connections in industrial networks.
  2. Unshielded Design: Suitable for low-EMI environments where shielding is not required.
  3. Straight Orientation: Simplifies cable routing for direct connections.
  4. Solder Contacts: Ensures a reliable and durable connection through soldering.
GeneralMaterialMechanicalEnvironmentalShellElectrical
General
Connector TypePlug
OrientationStraight
Contact TypeFemale Pin
Number of Positions5
KeyB
Contact TerminationSolder
Material
Shell MaterialPA66+GF
Contact FinishGold
Contact MaterialCopper Alloy
Mechanical
Fastening TypeThreaded
Mounting TypeCable Type
Environmental
Ingress ProtectionIP67
Operating Temperature-25°C ~ + 85°C
Shell
Shell SizeM8
Electrical
ShieldingUnshielded
Rated Current3A
Rated Voltage30V

Certification

M8 M12 M16 Connector AGC07686211202-002 REACH Download
Drawing for M8 Female Field Wireable Plug Unshielded Straight Solder Download
