RHT-634-3231-06
M8 Female Field Wireable Plug 6 Pos A Code Unshielded Straight Solder

Easily wire your connections with this M8 Female Field Wireable Plug. It features 6 positions, A code, unshielded design, and straight soldering capabilities, making it a convenient solution for your needs.

Color
  1. Black
Number of Positions
  1. 3
  2. 4
  3. 5
  4. 6
  5. 8
Compare

Product Type

Only 4 products can be compared at a time. Please select the product you want to replace.

    • Overview
    • Technical data
    • Catalog
    • Certificate

    Product certification

    1. General
    2. Shell
    3. Material
    4. Environmental
    5. Electrical

    General

    Connector TypePlug
    OrientationStraight
    Contact TypeFemale Pin
    Number of Positions6
    Fastening TypeThreaded
    Mounting TypeCable Type
    KeyA
    Contact TerminationSolder

    Shell

    Shell SizeM8

    Material

    Shell MaterialPA66+GF
    Contact FinishGold
    Contact MaterialCopper Alloy

    Environmental

    Ingress ProtectionIP67
    Operating Temperature-25°C ~ + 85°C

    Electrical

    ShieldingUnshielded
    Rated Current3A
    Rated Voltage30V
