RHT-634-3234-03

M8 Female Panel Mount Receptacle 3 Pin A Code Front Fastened Straight PCB Open Hole M10

Color:

Silver

Number of Positions:

34568
Get a Quote
Products >
  • Overview
  • Technical data
  • Certification
  • Download

Product certification

×

Product excerpt

  1. 3 Pins (A-Coded): Ensures precise and secure connections.
  2. A-Coded: Guarantees correct orientation.
  3. Front Fastened: Provides secure attachment to the panel from the front.
  4. Straight Orientation: Facilitates direct mounting on PCB.
  5. Open Hole Design: Offers flexibility for various mounting configurations.
GeneralMaterialMechanicalEnvironmentalShellElectrical
General
Connector TypeReceptacle
OrientationStraight
Contact TypeFemale Pin
Number of Positions3
KeyA
Contact TerminationThrough Hole
Material
Shell MaterialCopper Alloy
Shell FinishZinc Plated
Contact FinishGold
Contact MaterialCopper Alloy
Mechanical
Fastening TypeThreaded
Mounting TypePanel Mount
Mounting FeatureBulkhead
Environmental
Ingress ProtectionIP67
Operating Temperature-25°C ~ + 85°C
Shell
Shell SizeM8
Electrical
ShieldingUnshielded
Rated Current1.5A
Rated Voltage30V

Certification

M8 M12 M16 Connector AGC07686211202-002 REACH Download
Drawing for M8 Female Panel Mount Receptacle Front Fastened Straight PCB Open Hole Download

Catelog

RENHOTEC M-Series Connector Catalog [EN][CN] Download
