Products > Sensor Connector > M8 Female Panel Mount Receptacle 6 Pin A Code Front Fastened Straight PCB Open Hole M10

RHT-634-3234-06
M8 Female Panel Mount Receptacle 6 Pin A Code Front Fastened Straight PCB Open Hole M10

High-quality M8 female panel mount receptacle with 6 pins, A code, front fastened straight design for PCB open hole M10. Ideal for secure and reliable connections in various electronic applications.

Color
  1. Silver
Number of Positions
  1. 3
  2. 4
  3. 5
  4. 6
  5. 8
Compare

Product Type

Only 4 products can be compared at a time. Please select the product you want to replace.

    • Overview
    • Technical data
    • Catalog
    • Certificate

    Product certification

    1. General
    2. Shell
    3. Material
    4. Environmental
    5. Electrical

    General

    Connector TypeReceptacle
    OrientationStraight
    Contact TypeFemale Pin
    Number of Positions6
    Fastening TypeThreaded
    Mounting TypePanel Mount
    Mounting FeatureBulkhead
    KeyA
    Contact TerminationThrough Hole

    Shell

    Shell SizeM8

    Material

    Shell MaterialCopper Alloy
    Shell FinishZinc Plated
    Contact FinishGold
    Contact MaterialCopper Alloy

    Environmental

    Ingress ProtectionIP67
    Operating Temperature-25°C ~ + 85°C

    Electrical

    ShieldingUnshielded
    Rated Current1.5A
    Rated Voltage30V
    Каталог разъемов RENHOTEC 2PM [EN][RU] Download
    RENHOTEC M-Series Connector Catalog [EN][CN] Download
    M8 M12 M16 Connector AGC07686211202-002 REACH Download
