RHT-634-1301-04

M8 Female Panel Mount Receptacle 4 Pin A Code Front Fastened Straight Solder Cup Open Hole M12

Color:

Silver

Number of Positions:

34568
Get a Quote
Products >
  • Overview
  • Technical data
  • Certification
  • Download

Product certification

×

Product excerpt

  1. 4 Pins (A-Coded): Provides secure and precise connections.
  2. A-Coded: Ensures correct orientation and compatibility.
  3. Front Fastened: Attaches securely to the panel from the front side.
  4. Straight Orientation: Facilitates direct mounting on PCB (Printed Circuit Board).
  5. Solder Cup Contacts: Offers robust connections through soldering.
  6. Open Hole Design: Allows for versatile mounting and additional flexibility.
GeneralMaterialMechanicalEnvironmentalShellElectrical
General
Connector TypeReceptacle
OrientationStraight
Contact TypeFemale Pin
Number of Positions4
KeyA
Contact TerminationSolder Cup
Material
Shell MaterialCopper Alloy
Shell FinishZinc Plated
Contact FinishGold
Contact MaterialCopper Alloy
Mechanical
Fastening TypeThreaded
Mounting TypePanel Mount
Mounting FeatureBulkhead
Environmental
Ingress ProtectionIP67
Operating Temperature-25°C ~ + 85°C
Shell
Shell SizeM8
Electrical
ShieldingUnshielded
Rated Current3A
Rated Voltage60V

Certification

M8 M12 M16 Connector AGC07686211202-002 REACH Download
Drawing for M8 Female Panel Mount Receptacle Front Fastened Straight Solder Cup Open Hole Download

Catelog

RENHOTEC M-Series Connector Catalog [EN][CN] Download
