product image

RHT-634-3118-03

M8 3 Pin Male Right Angle Field Assembly Plug, A Code Unshielded, Solder Cup

Color:

Black

Number of Positions:

  • Overview
  • Technical data
  • Certification
  • Download

Product certification

Product excerpt

  1. Compact Design: Right-angle orientation allows for use in tight spaces, saving installation room.
  2. 3-Pin Configuration: Suitable for standard signal applications.
  3. A Code: Standard A Code configuration, typically used for signal connections rather than power.
  4. Unshielded: Cost-effective option for environments with minimal electrical interference.
  5. Screw Termination: Ensures a secure and stable connection.
  6. Field-Wireable: Allows for easy on-site wiring and adjustments, providing flexibility and adaptability.
EnvironmentalElectricalMaterialGeneralMechanicalShell
Environmental
Ingress ProtectionIP67
Electrical
Rated Current1.5A
Material
Shell MaterialPA66+GF
General
Connector TypePlug
Mechanical
Fastening TypeThreaded
Shell
Shell SizeM8

Certification

M8 M12 M16 Connector AGC07686211202-002 REACH Download

Catelog

RENHOTEC M-Series Connector Catalog [EN][CN] Download
Drawing for M8 Male Field Wireable Plug Unshielded Right Angle Screw Download
